The Miro Cube 2 range of LED fixtures is engineered to provide lighting designers and integrators with precision light control and tech-enabled solutions to execute their projects with accuracy and efficiency. Their sleek design is packed with state-of-the-art technology that provides maximum output and flicker-free dimming from a 4-in. (10 cm) cube-shaped LED light.
The Miro Cube 2 4C is an RGBW color-mixing fixture for producing bright and bold colors. The fixture’s white emitter can also be used to create tints and pastel colors.
The Miro Cube 2 4CA is an RGBA fixture that features a unique, phosphor-converted amber chip for creating rich warm-tones. The 4CA also produces a warm white light – as low as 2200K – that features a full color spectrum and high CRI.
The numerous features of these two fixtures make them an excellent choice for illuminating museums, themed environments, broadcast studios, or any installation that needs voluminous amounts of light – without large, bulky fixtures.
The Miro Cube 2 4C and 4CA are a 50-watt fixtures that utilize their full potential – no matter what hue or color temperature they’re producing. Our Patented Ludicrous Mode intelligently redistributes the fixture's power to maximize its output. Combine this feature with the patented Miro Cube heat management system and you’ve got an ultra-compact light fixture capable of producing incredibly high light output. The best part? You don’t have to do anything. Every Miro Cube 2 fixture ships with Ludicrous Mode already enabled.
Many projects simply program the light once – and then the settings never change. Even so, programming large projects can take up a lot of valuable time on a job site. Miro Cube 2 4C & 4CA fixtures can ship from the factory pre-programmed to a specified hue or color temperature. This removes the need to program the fixtures on-site – making integration much faster and easier.
Miro Cube 2 4C & 4CA fixtures can be controlled by many popular control options, including: RDM compatible DMX and 0-10VDC, or via a mobile device using the myMIX™ Connect accessory and the myMIX™ App. The fixture provides flicker-free dimming via 16kHz PWM in 8- or 16-bit resolution or via its unique NO PWM mode.
Miro Cube 2 also features our unique Master Dim Mode that enables users to set their desired color, or color temperature, then dim the fixture at that setting via a single control channel.
A Classic Conversion option, featuring the Powercon/XLR connectors and LCD user interface used in the original Miro Cube 4C & 4CA models, is also available.
Each Miro Cube 2 fixture ships with an OPTI-SCULPT Lens Kit that contains three Rosco OPTI-SCULPT Lenses: 20°, 30°, and the reversible 40°R60°. All of the other individual OPTI-SCULPT lenses are available for the Miro Cube 2 as well. Visit the Rosco OPTI-SCULPT product page to learn more about these unique beam-shaping lenses.
A range of beam control accessories are also available for the Miro Cube 2, including Barn Doors, Top Hats and an Egg Crate Louver.
A good lighting design doesn’t draw attention to the fixtures. It’s important, however, to have a well-designed fixture – just in case anyone ever looks up. From its rounded corners and side accent panels, to the yoke marks that enable precise focus angles – every element of the Miro Cube 2 design has been purposefully thought out. Whether they’re illuminating a museum, a house of worship, or a retail store – the universal design of the Miro Cube 2 lighting fixtures will feel at home in any venue.
Not every project needs black or white fixture housings. Sometimes the lights need to match the color scheme of the rest of the design. Not only can the housing color of the Miro Cube 2 be specified into a wide range of RAL colors, but the fixture’s side accent panels can also be customized to provide a two-tone aesthetic.
What’s In The Box:
|
Input Voltage: |
90-240VAC 50/60H |
|
Power Consumption: |
50W |
|
Power Input: |
Hard-wired pigtail, 6 feet/1.82 meters |
|
Lumen Maintenance: |
72,600 hours at L80 at 45ºC |
|
Data Connector: |
RJ45 In/Out Connectors |
|
4C |
4CA |
|
Max Output: 1443lm |
Max Output: 1135lm |
|
Color Temp. Range: 3200K – 10,000K |
Color Temp. Range: 2200K – 10,000K |
|
Avg. CRI (White Light): 80+ |
Avg. CRI (White Light): 92+ |
|
LED Color Specifications: |
LED Color Specifications: |
|
True Rosco Color™ Gel Matches: 44 |
True Rosco Color™ Gel Matches: 54 |
|
Operation: |
DMX RDM or 0-10V Dimmable |
|
Operating Temp.: |
-13º to 113ºF (-20º to 45º C) |
|
Humidity: |
0-95% non-condensing |
|
Dimensions: |
4.3 in x 4.3 in x 4.9 in (109mm x 109mm x 125mm) |
|
Weight: |
2.1 lbs (0.95 kg) |
|
Housing: |
Powder coated, die-cast aluminum |
|
Finish: |
Black, White, Custom |
|
IP Rating: |
IP20 |
|
DMX Channels: |
1,2,4,5,8 |
|
myMIX® Connect Compatible |
|
Miro Cube 2 4C & 4CA – Classic Conversion
(Same as above, except for the following:)
What’s In The Box:
|
Power Input: |
Neutrik Powercon, 6.56 feet/2 meters |
|
Data Connector: |
5-Pin XLR In/Out connectors |
|
Operation: |
DMX RDM + Full Text LCD screen user-interface |
|
Finish: |
Black Only |
|
Miro Cube 2 Approvals: |
cETL, ETL, CE, UKCA, FCC Class A Compliant; Dry Locations |
Introducing Miro Cube® 2
Miro Cube® 2 ARC DWG Files (Zip)
Miro Cube® 2 ENT DWG Files (Zip)
myMIX® for iOS
Case Study: Rosco LED Lights Illuminate The History Of The U.S. Army
Case Study: Lighting The Journey Inside Changi Experience Studio
Rosco and The Black Tank – A Strategic Partnership
Please complete this form
The myMIX Connect RJ45 dongle enables lighting professionals to control a Miro Cube® 2 from their mobile device using the myMIX® app.
The dongle is self-powered from the Miro Cube 2, so no external power supply is required.
Download the myMIX App For iOS®:
Download the myMIX App For iOS
Download the myMIX Connect User Manual:
Download the myMIX Connect User Manual
Rosco OPTI-SCULPT lenses provide precise angular beam control to accurately control the shape of the light with increased brightness over other diffusion filters. Our proprietary OPTI-SCULPT manufacturing process features engineered light distribution that has been laboratory tested for accuracy and repeatability.
This kit of symmetrical OPTI-SCULPT lenses is the same kit that is included with the Miro Cube 2 4C, 4CA, and WNC fixtures. Each kit contains three lenses: 20°, 30°, and a reversible 40°R60° OPTI-SCULPT lens.
Visit the OPTI-SCULPT product page to learn more about the properties of these unique beam-shaping lenses.
Additional OPTI-SCULPT Lens accessories are also available for the Miro Cube 2.
Note: OPTI-SCULPT is not intended for use with the Miro Cube 2 UV365 black light.
Rosco OPTI-SCULPT lenses provide precise angular beam control to accurately control the shape of the light with increased brightness over other diffusion filters. Our proprietary OPTI-SCULPT manufacturing process features engineered light distribution that has been laboratory tested for accuracy and repeatability. Visit the OPTI-SCULPT product page to learn more about the properties of these unique beam-shaping lenses.
An OPTI-SCULPT Lens Kit is included with the 4C, 4CA, and WNC Miro Cube 2 models. The kit contains three symmetrical lenses: 20°, 30°, and a reversible 40°R60° OPTI-SCULPT lens. All OPTI-SCULPT lenses are available as an accessory for the Miro Cube 2. Note: OPTI-SCULPT is not intended for use with the Miro Cube 2 UV365 black light.
Four-leaf set of barn doors that provides multiple beam shaping options.
Provides 360° beam control to control spill and reduce glare to the viewing audience.
Controls spill, narrows the beam angle, and reduces glare to the viewing audience.
The Rosco Pole Mount is a rugged mounting accessory for attaching Rosco Projectors and Rosco Cube products to interior or exterior round poles.
Powder-Coated Steel support that provides rigid attachment and a clean, mounted installation.
1-3/5” (42mm) open tubing provides room for power/data cables for a clean installation.
Pole Mounts attach to any round structure via Stainless Steel Straps (kit sold separately).
Product Numbers:
The Rosco Surface Mount allows for mounting Rosco Projectors and Rosco Cubes to interior or exterior horizontal surfaces.
Powder-Coated Steel support that provides rigid attachment and a clean, mounted installation.
1-3/5” (42mm) open tubing provides room for power/data cables for a clean installation.
Product Numbers:
The Rosco Wall Mount allows for mounting Rosco Projectors and Rosco Cubes to interior or exterior vertical surfaces.
Powder-Coated Steel support that provides rigid attachment and a clean, mounted installation.
1-3/5” (42mm) open tubing provides room for power/data cables for a clean installation.
Product Numbers:
RJ45 to 5-Pin XLR Adaptor
5-Pin XLR to RJ45 Adaptor
